DJMP Series NEMA Premium, Three Phase, Rolled Steel, Open Drip Proof (ODP) General Purpose Motors On Gainesville Industrial Electric Co.

1011 Athens Street
Gainesville, GA 30501 USA

Gainesville Industrial Electric

ASGHJM, NEMA Premium, Close Coupled, (1 HP - 40 HP)

1 - 25 of 31 | Results Per Page | View | Unit of Measure

1 2

Request Information Compare Items Search by Specification

Item #	Item Name	Power	Speed	Frame

DJMP0014	N/A DJMP Series 1 Horsepower (hp), 143/145JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 1 hp	N/A 1800 rpm	N/A 143/145JM
DJMP0016	N/A DJMP Series 1 Horsepower (hp), 143/145JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 1 hp	N/A 1200 rpm	N/A 143/145JM
DJMP1/52	N/A DJMP Series 1.5 Horsepower (hp), 143/145JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 1.5 hp	N/A 3600 rpm	N/A 143/145JM
DJMP1/54	N/A DJMP Series 1.5 Horsepower (hp), 143/145JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 1.5 hp	N/A 1800 rpm	N/A 143/145JM
DJMP1/56	N/A DJMP Series 1.5 Horsepower (hp), 182/184JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 1.5 hp	N/A 1200 rpm	N/A 182/184JM
DJMP0022	N/A DJMP Series 2 Horsepower (hp), 143/145JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 2 hp	N/A 3600 rpm	N/A 143/145JM
DJMP0024	N/A DJMP Series 2 Horsepower (hp), 143/145JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 2 hp	N/A 1800 rpm	N/A 143/145JM
DJMP0026	N/A DJMP Series 2 Horsepower (hp), 182/184JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 2 hp	N/A 1200 rpm	N/A 182/184JM
DJMP0032	N/A DJMP Series 3 Horsepower (hp), 143/145JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 3 hp	N/A 3600 rpm	N/A 143/145JM
DJMP0034	N/A DJMP Series 3 Horsepower (hp), 182/184JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 3 hp	N/A 1800 rpm	N/A 182/184JM
DJMP0036	N/A DJMP Series 3 Horsepower (hp), 213/215JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 3 hp	N/A 1200 rpm	N/A 213/215JM
DJMP0052	N/A DJMP Series 5 Horsepower (hp), 182/184JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 5 hp	N/A 3600 rpm	N/A 182/184JM
DJMP0054	N/A DJMP Series 5 Horsepower (hp), 182/184JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 5 hp	N/A 1800 rpm	N/A 182/184JM
DJMP0056	N/A DJMP Series 5 Horsepower (hp), 213/215JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 5 hp	N/A 1200 rpm	N/A 213/215JM
DJMP7/52	N/A DJMP Series 7.5 Horsepower (hp), 182/184JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 7.5 hp	N/A 3600 rpm	N/A 182/184JM
DJMP7/54	N/A DJMP Series 7.5 Horsepower (hp), 213/215JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 7.5 hp	N/A 1800 rpm	N/A 213/215JM
DJMP7/56	N/A DJMP Series 7.5 Horsepower (hp), 254/256JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 7.5 hp	N/A 1200 rpm	N/A 254/256JM
DJMP0102	N/A DJMP Series 10 Horsepower (hp), 213/215JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 10 hp	N/A 3600 rpm	N/A 213/215JM
DJMP0104	N/A DJMP Series 10 Horsepower (hp), 213/215JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 10 hp	N/A 1800 rpm	N/A 213/215JM
DJMP0106	N/A DJMP Series 10 Horsepower (hp), 254/256JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 10 hp	N/A 1200 rpm	N/A 254/256JM
DJMP0152	N/A DJMP Series 15 Horsepower (hp), 213/215JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 15 hp	N/A 3600 rpm	N/A 213/215JM
DJMP0154	N/A DJMP Series 15 Horsepower (hp), 254/256JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 15 hp	N/A 1800 rpm	N/A 254/256JM
DJMP0156	N/A DJMP Series 15 Horsepower (hp), 284/286JM Frame, and 1200 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 15 hp	N/A 1200 rpm	N/A 284/286JM
DJMP0202	N/A DJMP Series 20 Horsepower (hp), 254/256JM Frame, and 3600 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 20 hp	N/A 3600 rpm	N/A 254/256JM
DJMP0204	N/A DJMP Series 20 Horsepower (hp), 254/256JM Frame, and 1800 Revolutions Per Minute (rpm) Speed Rolled Steel Open Drip Proof (ODP) General Purpose Motor	N/A 20 hp	N/A 1800 rpm	N/A 254/256JM
