  • IXHHI Model - Explosion Proof, Premium Efficiency Three Phase, TEFC, C-Face, Foot Mounted Electric Motors
  • IXHHI Model - Explosion Proof, Premium Efficiency Three Phase, TEFC, C-Face, Foot Mounted Electric Motors - 2
Features
  • Insulation Class F, Temperature rise B or F, 40 ºC ambient
  • 230/460 V (~ 125 HP), 460 V (150 HP ~ 250 HP)
  • Class 1 Division 1 Group C&D Temp. code T4 with Thermostat (1 EA/Ph.)
  • Cast Iron construction, Direct-on-line & Inverter duty
  • IP55, Diagonally split, Gasketed terminal box, Fully rotatable at 90 increments
  • Tap provision for Vib. sensor & Bearing Temp. Detector (Except Vib. sensor & Bearing Temp. Detector)
1 - 25 of 37 | Results Per Page | View | Unit of Measure
1 2
Request Information Compare Items Search by Specification

Item #

Item Name

Power

Frame Number

Speed

Voltage

N/A IXHHI Model 1 Horsepower (hp) Power and 3490 Revolutions Per Minute (rpm) Speed Electric Motor N/A 1 hp N/A 143TC N/A 3490 rpm N/A 230 V460 V
N/A IXHHI Model 1 Horsepower (hp) Power and 1755 Revolutions Per Minute (rpm) Speed Electric Motor N/A 1 hp N/A 143TC N/A 1755 rpm N/A 230 V460 V
N/A IXHHI Model 1 Horsepower (hp) Power and 1155 Revolutions Per Minute (rpm) Speed Electric Motor N/A 1 hp N/A 145TC N/A 1155 rpm N/A 230 V460 V
N/A IXHHI Model 1.5 Horsepower (hp) Power and 3485 Revolutions Per Minute (rpm) Speed Electric Motor N/A 1.5 hp N/A 143TC N/A 3485 rpm N/A 230 V460 V
N/A IXHHI Model 1.5 Horsepower (hp) Power and 1750 Revolutions Per Minute (rpm) Speed Electric Motor N/A 1.5 hp N/A 145TC N/A 1750 rpm N/A 230 V460 V
N/A IXHHI Model 1.5 Horsepower (hp) Power and 1175 Revolutions Per Minute (rpm) Speed Electric Motor N/A 1.5 hp N/A 182TC N/A 1175 rpm N/A 230 V460 V
N/A IXHHI Model 2 Horsepower (hp) Power and 3480 Revolutions Per Minute (rpm) Speed Electric Motor N/A 2 hp N/A 145TC N/A 3480 rpm N/A 230 V460 V
N/A IXHHI Model 2 Horsepower (hp) Power and 1745 Revolutions Per Minute (rpm) Speed Electric Motor N/A 2 hp N/A 145TC N/A 1745 rpm N/A 230 V460 V
N/A IXHHI Model 2 Horsepower (hp) Power and 1175 Revolutions Per Minute (rpm) Speed Electric Motor N/A 2 hp N/A 184TC N/A 1175 rpm N/A 230 V460 V
N/A IXHHI Model 3 Horsepower (hp) Power and 3520 Revolutions Per Minute (rpm) Speed Electric Motor N/A 3 hp N/A 182TC N/A 3520 rpm N/A 230 V460 V
N/A IXHHI Model 3 Horsepower (hp) Power and 1770 Revolutions Per Minute (rpm) Speed Electric Motor N/A 3 hp N/A 182TC N/A 1770 rpm N/A 230 V460 V
N/A IXHHI Model 3 Horsepower (hp) Power and 1185 Revolutions Per Minute (rpm) Speed Electric Motor N/A 3 hp N/A 213TC N/A 1185 rpm N/A 230 V460 V
N/A IXHHI Model 5 Horsepower (hp) Power and 3515 Revolutions Per Minute (rpm) Speed Electric Motor N/A 5 hp N/A 184TC N/A 3515 rpm N/A 230 V460 V
N/A IXHHI Model 5 Horsepower (hp) Power and 1760 Revolutions Per Minute (rpm) Speed Electric Motor N/A 5 hp N/A 184TC N/A 1760 rpm N/A 230 V460 V
N/A IXHHI Model 5 Horsepower (hp) Power and 1180 Revolutions Per Minute (rpm) Speed Electric Motor N/A 5 hp N/A 215TC N/A 1180 rpm N/A 230 V460 V
N/A IXHHI Model 7.5 Horsepower (hp) Power and 3530 Revolutions Per Minute (rpm) Speed Electric Motor N/A 7.5 hp N/A 213TC N/A 3530 rpm N/A 230 V460 V
N/A IXHHI Model 7.5 Horsepower (hp) Power and 1775 Revolutions Per Minute (rpm) Speed Electric Motor N/A 7.5 hp N/A 213TC N/A 1775 rpm N/A 230 V460 V
N/A IXHHI Model 7.5 Horsepower (hp) Power and 1175 Revolutions Per Minute (rpm) Speed Electric Motor N/A 7.5 hp N/A 254TC N/A 1175 rpm N/A 230 V460 V
N/A IXHHI Model 10 Horsepower (hp) Power and 3525 Revolutions Per Minute (rpm) Speed Electric Motor N/A 10 hp N/A 215TC N/A 3525 rpm N/A 230 V460 V
N/A IXHHI Model 10 Horsepower (hp) Power and 1770 Revolutions Per Minute (rpm) Speed Electric Motor N/A 10 hp N/A 215TC N/A 1770 rpm N/A 230 V460 V
N/A IXHHI Model 10 Horsepower (hp) Power and 1175 Revolutions Per Minute (rpm) Speed Electric Motor N/A 10 hp N/A 256TC N/A 1175 rpm N/A 230 V460 V
N/A IXHHI Model 15 Horsepower (hp) Power and 3550 Revolutions Per Minute (rpm) Speed Electric Motor N/A 15 hp N/A 254TC N/A 3550 rpm N/A 230 V460 V
N/A IXHHI Model 15 Horsepower (hp) Power and 1775 Revolutions Per Minute (rpm) Speed Electric Motor N/A 15 hp N/A 254TC N/A 1775 rpm N/A 230 V460 V
N/A IXHHI Model 15 Horsepower (hp) Power and 1175 Revolutions Per Minute (rpm) Speed Electric Motor N/A 15 hp N/A 284TC N/A 1175 rpm N/A 230 V460 V
N/A IXHHI Model 20 Horsepower (hp) Power and 3550 Revolutions Per Minute (rpm) Speed Electric Motor N/A 20 hp N/A 256TC N/A 3550 rpm N/A 230 V460 V
